Acousti AFG80B Anti-vibration 80mm Fan Gasket
AFG80B
58 In Stock

These super-soft silicone fan gaskets are designed to dramatically reduce the vibration from any PC or server case cooling fans. The 60 and 70mm gaskets are 1.5mm thick, and the larger sizes are 2.5mm thick. Included with each gasket are silicone washers and anti-vibration screws. These screws feature a thread design which prevents the shank touching the fan and vibrations being transmitted and amplified through to the chassis.

These gaskets are suitable for the vast majority of case designs and fan combinations, as they fit standard fan mounting holes. Slightly lengthened (12mm thread) fan mounting screws are supplied with the fan gaskets and washers. These gaskets can be used with standard PC cooling fans, and not just with AcoustiFan™ quiet case fans. Note: Do not use these gaskets in very high temperature locations inside a PC/Server such as attached to CPU or GPU heat sinks!

Advantages

  • Help to absorb the vibration that otherwise would be transmitted from the fan into the case chassis and case housing.
  • Help to ‘seal’ the small gap between the fan and the casing/enclosure wall. This improves the efficiency of the fan, by reducing feedback airflow and therefore air pressure losses.

Other advantages include:

  • Compatible with virtually all case cooling fans
  • Supplied with screws and silicone washers
  • Quick and very easy to fit (these gaskets ‘hold onto’ the fan whilst fitting them due to a small lip in the gasket design)

Technical Spec

  • Operating Temperature: (-)20 - (+)70°C
  • Softness: Shore A 40 +/-5
  • Material: Translucent Silicon Rubber
  • Gasket Thickness: 2.5mm
  • Recommended Compression: 5% of height

Technical Drawing of 120mm Silicone Fan Gasket. The silicone for the gasket is 2.5mm thick, and the silicone for the washer is 2.0mm thick.

These gaskets are suitable for the vast majority of case designs and fan combinations, as they fit standard fan mounting holes. Slightly lengthened (12mm thread) fan mounting screws are supplied with the fan gaskets and washers. These gaskets can be used with standard PC cooling fans, and not just with AcoustiFan™ quiet case fans. Note: Do not use these gaskets in very high temperature locations inside a PC/Server such as attached to CPU or GPU heat sinks!

Fitting Directions

  1. Fit the fan gasket onto the outside of the fan housing (it will stay on the fan)
  2. Position the fan and gasket together against the inside of the case, so that the four mounting holes in the fan and gasket line up to the mounting holes in the case side
  3. Locate the four silicone washers and screws, and fit the washers against the case side, each secured by a screw
  4. Tighten the screws enough to very slightly compress the silicone rubber. Do not overtighten.

Animation showing a vibration-reducing silicone fan gasket fitted to a standard case cooling fan, and fastened into position with a screw and external silicone washer.

Effective? - Yes, these are simply the most effective yet!

Why are these silicone fan gaskets especially effective? Because Acousti Products have not held back on the silicone thickness and the silicone material softness. All gaskets are 2.5mm thick (not just 1mm like alternatives), and Shore A 40 (a great deal softer than others we have tested). We are confident that these two factors make these gaskets more effective than any other models available.

£3.04 (£2.53 ex VAT)
RJ45 double adapter - 3 x RJ45 sockets
l_88.102
In Stock
These allow three UTP or ISDN cables to be coupled. They will allow two computers to share one connection point, but with only one computer in operation at a time
£2.78 (£2.32 ex VAT)
CiT 450W Black Edition PSU 12cm Dual 12v CE PFC Model 450UB
PSUCIT450UB
724 In Stock

Features
New Version Ver. 2.2
Cooling: 12cm Silent Fan
Silent and Better Ventilation
ATX 12V Compliant for all Types of CPU and Mainboard
Dual 12v Rails
CE & PFC Approved

Specifications
Dimensions: 150mm x 85mm x 158mm (W x H x D)
Input Voltage: 230 VAC
Input Current: 5A
Input Frequency Range: 50-60Hz
PFC: PPFC
Power Good Signal: 150-450 ms
Hold Up Time: 1MS-40MS
Efficiency: 75%
MTBF: 100,000 Hours
Protection: OVP / UVP/ OPP
Power: 450W
Operation Temperature: 45°C
Safety: CE / ROHS
Cooling: 12cm Fan
Noise: < 17 dBA

£20.28 (£16.90 ex VAT)
Evercool 30mm 3cm 30x10 3 Pin 5 Volt Fan (M)
EC3010M05EA
-71 In Stock
Fan Description VDC Current
AMP
Input
Watts
Fan Speed AirFlow (Max) CFM Pressure
MMH2O
Noise
dBA
Fan Depth Fan Size Life/Hours
3010M05 5 0.18 0.9 8000 3.28 0.17 <22 10mm 30x30mm 40000

Cable Length = Approx 25cm (Fan edge to end of connector), No Screws.
£3.49 (£2.91 ex VAT)
Out of Stock
ACE 620W Grey PSU 12cm Fan SATA 24-Pin Model 620W
PSUACE62012CM
0 In Stock

Features
New Version 1.3 / Ver. 2.03
Cooling: 12cm Fan
Silent and Better Ventilation
ATX 12V Compliant for all Types of CPU and Mainboard
CE Approved
Input Voltage: 115Vac or 230Vac or 115Vac / 230Vac
2 x SATA Connectors
3 x Molex Connectors
20+4 Pin Motherboard Connector

Specifications
Dimensions: 150mm x 85mm x 158mm (W x H x D)
Input Voltage: 230 VAC
Input Current: 10A
Input Frequency Range: 50-60Hz
PFC: No
Power Good Signal: 150-450 ms
Hold Up Time: 1MS-40MS
Efficiency: 75%
MTBF: 100,000 Hours
Protection: OVP / UVP/ OPP
Power: 620W
Operation Temperature: 45°C
Safety: CE / ROHS
Cooling: 12cm Fan
Noise: < 17 dBA

£10.92 (£9.10 ex VAT)
Out of Stock
Thermaltake Pacific RL 240 Watercooling Kit/Diy 240mm
TTWCPACIFICRL240
Thermaltake Pacific RL 240 Watercooling Kit/Diy 240mm
£341.64 (£284.70 ex VAT)
Thermaltake Pacific 1/2'' ID x 5/8'' OD Compression Black/DIY LCS/Fitting
TTWCCLW031CA00BLA
Thermaltake Pacific 1/2'' ID x 5/8'' OD Compression Black/DIY LCS/Fitting
£7.18 (£5.98 ex VAT)
Qwerty Track 2.4GHz Wireless Keyboard with Trackball
KBQWERTYTRACK
-13 In Stock
Track 2.4GHz Wireless Keyboard with Trackball
£10.14 (£8.45 ex VAT)
Out of Stock
DB25 male to male 1.8m
l_32.103B
In Stock
These cables have all 25 lines connected 1:1. Their main use is to connect the parallel port to a DB25 switch box
£2.85 (£2.38 ex VAT)
